50~200℃ Industrial Heating Circulator/ Circulating Heater

Circulating heaters are used to provide high temperature experiment such as chemical, biological and physical experiment in low temperature. It is normally used for heating evaporators, distillation equipment, reactors, filtraion, etc.

High Quality Circulation Pumps and Heating Parts for High Reliability and Efficiency
Digital Setting and Display of Temperature for Easy Operation
Strong Heating Power and Fast Heating Up
Low Noise and Stable Constant Running with Low Maintenance Rates
Built-in Oil Tank for Higher Security Level
Accurate Temperature Control to Provide A Constant Temperature


Availability:



Inquiry Email

Model:
VH-25020
Brand:
Valuen

Product Overview

Product Parameter

About US

High Quality Circulation Pumps and Heating Parts for High Reliability and Efficiency

Digital Setting and Display of Temperature for Easy Operation

Strong Heating Power and Fast Heating Up

Low Noise and Stable Constant Running with Low Maintenance Rates

Built-in Oil Tank for Higher Security Level

Accurate Temperature Control to Provide A Constant Temperature

50~200℃-heater（生产型）

heater_11

heater_22

heater_33

Model	VH-15020	VH-25020	VH-38020	VH-60020	VH-95020	VH-130020	VH-200020
Temperature Range	50℃～200℃
Controller	LCD displays setting temperature and measure temperature, touch button input (Optional: touch screen with displaying temperature curves)
Cooling Mode	Water cooling
Heating Mode	Electric heating
Temperature Control Accuracy	±0.5℃		±1℃				±2℃
Heating Power	15KW	25KW	38KW	60KW	95KW	130KW	200KW
Circulation Pump Flow Rate	Max50L/min	Max110L/min	Max110L/min	Max250L/min	Max250L/min	Max400L/min	Max400L/min
Circulation Pump Pressure	2.0BAR	2.0BAR	2.0BAR	2.0BAR	2.0BAR	2.0BAR	2.0BAR
Safety Protection	High pressure switch, overload relay, thermal protection device and other safety guarantee functions
Interface Size	DN25	DN25	DN25	DN40	DN40	DN50	DN50
Weight	100KG	130KG	170KG	285KG	318KG	450KG	685KG
Power Supply Options	220V 60HZ 3-phase，440V～480V 60HZ 3-phase
Explosion-proof Options	ExdIIBT4 or ExdIICT4
