50~300℃ Heating Circulator/ Circulating Heater

Circulating heaters are used to provide high temperature experiment such as chemical, biological and physical experiment in low temperature. It is normally used for heating evaporators, distillation equipment, reactors, filtraion, etc.

High Quality Circulation Pumps and Heating Parts for High Reliability and Efficiency
Digital Setting and Display of Temperature for Easy Operation
Strong Heating Power and Fast Heating Up
Low Noise and Stable Constant Running with Low Maintenance Rates
Built-in Oil Tank for Higher Security Level
Accurate Temperature Control to Provide A Constant Temperature


Availability:



Inquiry Email

Model:
VH-5030
Brand:
Valuen

Product Overview

Product Parameter

About US

High Quality Circulation Pumps and Heating Parts for High Reliability and Efficiency

Digital Setting and Display of Temperature for Easy Operation

Strong Heating Power and Fast Heating Up

Low Noise and Stable Constant Running with Low Maintenance Rates

Built-in Oil Tank for Higher Security Level

Accurate Temperature Control to Provide A Constant Temperature

50~300℃-heater（小型）

heater_11

heater_22

heater_33

Model	VH-3030	VH-5030	VH-10030
Temperature Range	50℃～300℃
Controller	LCD displays setting temperature and measure temperature, touch button input (Optional: touch screen with displaying temperature curves)
Cooling Mode	Water colling
Heating Mode	Electric heating
Temperature Control Accuracy	±0.5℃
Heating Power	3.5KW	5.5KW	10KW
Circulation Pump Flow Rate	Max30L/min	Max30L/min	Max50L/min
Circulation Pump Pressure	2.0BAR	2.0BAR	2.0BAR
Safety Protection	High pressure switch, overload relay, thermal protection device and other safety guarantee functions
Interface Size	DN-20 PN-10
Weight	85KG	95KG	105KG
Power Supply	AC380V50HZ 3.2KW(max)	AC380V50HZ 5.9KW(max)	AC380V50HZ 10.8KW(max)
Power Supply Options	220V 60HZ 3-phase，440V～480V 60HZ 3-phase
Explosion-proof Options	ExdIIBT4 or ExdIICT4
